Bergamont E-Cargoville LJ Edition
Model : 290944
Key Features
- 20/26", lite AL-6061 tubing, 70x45//50x45 cm load platform, PowerTube battery
- BGM Cargo rigid fork, extra strong, Thru-axle
- Shimano Deore Linkglide, 1x10
- Bosch BES3 Performance Line, 500 Wh battery
- Magura CMe5, hydraulic 4-piston disc
- Ryde Andra 40 rims, BGM Cargo hub
- Schwalbe Pick-Up, Super Defence, 62-406 / 62-559
- B&M Myc LED, 50 Lux / BGM LED
1. Size
SPECIFICATIONS
-
The entry level E-Cargoville, with perfectly integrated Bosch Performance Line drive unit, reliable Shimano Deore group-set and powerful Magura brake system. Configurable with short or long front section. Option to mount a second battery for increased range.
condition of usage 1 -
Frame
20/26", lite AL-6061 tubing, 70x45//50x45 cm load platform, PowerTube battery -
Fork
BGM Cargo, rigid fork, extra strong, 15x100 mm axle -
Drive Unit
Bosch Performance Line, Gen. 3, BES3, 250 W, 36 V, max. 25 km/h -
Battery
Bosch PowerTube, 36 V Li Ion, 500 Wh
-
Display
Bosch LED Remote with Intuvia 100 display -
Charger
Bosch Standard Charger, 4A -
Rear Derailleur
Shimano Deore Linkglide, RD-M5130, Shadow Plus -
Shifters
Shimano Deore Linkglide, SL-M5130, 1x10-speed, rapidfire plus-shifter -
Crankset
FSA CK-320, 38t -
BB-Set
Bosch, Isis -
Chain
Shimano Linkglide, CN-LG500 -
Cassette
Shimano Linkglide, CS-LG600-10, 11-43t -
Brake Levers
Magura CMe5, hydraulic disc brake -
Brakes
Magura CMe5, hydraulic disc brake, 4-piston -
Rotor
Magura MDR-C, 180 mm -
Handlebar
BGM Pro, riserbar, backsweep: 30°, rise: 5 mm -
H'stem
BGM Cargo, adjustable -
Seatpost
BGM Pro -
Seat
Syncros Capilano Trekking Memory Foam -
Headset
Cane Creek Visco-Set, A-Headset, semi-integrated, tapered (fork) / FSA IS-3E, A-Headset, 1-1/8" (steering tube) -
Hub (Front)
BGM Pro Cargo, 6-bolt, disc, 15x100 mm axle, quad bearing -
Hub (Rear)
Shimano Deore XT, FH-M8000, centerlock, disc, quick release -
Spokes
Sapim Leader -
Rims
Ryde Andra 40, disc -
Front Tire
Schwalbe Pick-Up, Super Defence, 62-406
Tube: Impac AV20 -
Rear Tire
Schwalbe Pick-Up, Super Defence, 60-559
Tube: Impac AV26 -
Lights
Front: B&M Myc, 50 Lux, LED
Rear: B&M Bergamont Special LED, integrated in fender -
Pedals
Trekking alloy -
Accessories
Kickstand: BGM custom Cargo center-stand, 2-legged -
Approx weight in KG
28,8 -
Color
shiny white -
Fender
Racktime Alumee -
Frame size
one size -
Grips
BGM Comfort, Ergo, double density, clamp version -
Max. System Weight
220,0 kg
The overall weight includes the bike, the rider, the equipment and possible additional luggage.
Use
No Radar Chart Available Currently
Geometry

one size | |||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
A | BB center to top of seattube | 495 mm | |||||||||||||||||
B | top tube parallel | 558 mm | |||||||||||||||||
B* | top tube horizontal | 589 mm | |||||||||||||||||
C | chainstay | 468 mm | |||||||||||||||||
D | headtube length | 125 mm | |||||||||||||||||
E | head angle | 68,0 ° | |||||||||||||||||
F | seat angle | 71,0 ° | |||||||||||||||||
H | BB offset | -65 mm | |||||||||||||||||
K | wheelbase | 2.035 mm | |||||||||||||||||
L | standover height | 436 mm | |||||||||||||||||
M | stack | 610 mm | |||||||||||||||||
N | reach | 379 mm | |||||||||||||||||
fork length | 328 mm | ||||||||||||||||||
fork rake | 46 mm |
G | seatpost diameter | 31,6 mm |
I | shock dimension | |
headset dimension | ZS44/ZS56 & IS41 | |
BB standard | Bosch Gen3 | |
hanger type | BGM-H048CD / BGM-H048AD | |
max. rotor size | 203 mm |
